600 type wood chipper integrates slicing and crushing, and can cut branches and branches with a diameter of 1-20 cm. The branch crusher is mainly used to process pine, miscellaneous wood, poplar, Chinese fir, raw bamboo and other materials, which is more suitable for wood chip machine processing in edible fungus culture medium. At the same time, the equipment can also be used for cutting fibrous stalk materials such as bamboo, thatch, corn stalk and sorghum stalk. The sawdust crusher can also be used as raw material for particleboard, sawdust board and high density board This series of equipment is suitable for mobile operation. It is widely used in the material preparation section of small and medium-sized particleboard and fiberboard production enterprises. It can also be used for individual households to produce commercial wood chips.
1. It is strictly forbidden to operate the branch crusher beyond the standard to crush materials, so as not to damage the equipment and cause unnecessary trouble;
2. The branch crusher needs to regularly check the oil quantity of the bearing on the motor and equipment, and the bearing part cannot be short of oil (add high-speed butter);
3. Before the operation of the branch crusher, check whether the tightness of the belt is worn, so as to facilitate the normal operation of the equipment;
4. Before crushing, the branch crusher must check whether there are nails and sundries on and in the raw materials, so as not to damage the screen holes and tools and cause unnecessary losses.
Fruit tree branch crusher is mainly used for crushing various light materials, such as bamboo chips, twigs, dumb branches, corn, sorghum, wheat, beans, corn straw, peanut seedlings, sweet potato seedlings, peanut skin, dry weeds and other miscellaneous grains, dry feeds and coarse crushed cakes. It is mainly used for primary crushing of these materials. The machine can be used for mobile operation in open sites and high-efficiency operation in fixed sites. The use mode of fruit tree branch crusher is flexible and convenient. It is a necessary equipment for your garden waste treatment, pruning branches, crushing and fertilization. The broken branches of the machine can also be used in machine-made charcoal production, sawdust board manufacturing and other industries
Device Model | 600 Type wood chipper | Feed roller power | Hydraulic motor |
power | Motor drive | Hydraulic oil tank capacity | 24L |
Yield | 800-2000kg /h | Feed throat size | 310mm×200mm |
Dimensions | L2320mm×W1400mm×H1950mm | Tire size | 165/70r13 |
Knife roller diameter | 300mm | Wheel size | 13 inch steel ring |
Power | 25Hp-54Hp/22Kw | Generator power | 1000w |
Processing branch diameter | 120mm | 650-750kg | |
Startup method | Electric start | Battery Specifications | 12V 85aH |
Host speed | 2600r/min | Feeding speed | 22m/min |
Number of blades | 4 moving knives and 1 static knife | Chassis height | 270mm |
Blade length | 155mm | Material moisture content | Unlimited |
Feed roller diameter | 280mm | Maximum material hardness | Wood type: Unlimited |
Discharge direction | 360-degree quick adjustment device | Feeding gear | Three-speed manual control: forward, reverse and stop |
Degree of crushing | Coarse crusher | Throttle and flameout control | Front-mounted throttle and flameout integrated operation handle |
Accessories | Tool set (single cylinder diesel engine) | Customization related | Support special requirements customization |
Other Configuration | Tail light, feeding light, foldable hand jack, adjustable towing height | ||
The above parameters are for reference only, please refer to the actual product
